Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
I am currently making a dream come true with this one as it's been on my wish list for a while: Wish list"/> During the process, I realized that there was much more customization required than it looked at first start. Among the trickiest parts, I had to shave 3/8" (5mm) to the cab and relocate all equipment on the front end of the truck's frame. The Titan version I used was the latest generation but the Dakar Titan from Mammoet seems older generation which I have no clue how old it is. Of sourse, I used that military Titan 8x8 by WSI for most parts: "/> Then I also needed to rework all the intake/fuel cell and weld the sidebars in brass. The ballast box/fenders/service crane will be machined in steel sheets as I typically do for my custom jobs. Here's how it goes so far: "/> "/> "/> "/>
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
By the way, if anyone has pictures of that truck, I would need to have one showing the opposite side. Then maybe a back view would also be nice to have.
I cannot find any via Google. That would be much appreciated....
Stephane
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 11/8/2005 Posts: 199 Location: Kinross, Scotland
|
These any good Steph, Mammoet TitanRegards Joe.
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Oh yeah, excellent. Thanks! Stephane
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 1/14/2006 Posts: 667 Location: The Netherlands
|
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Yes, thanks anyways. For some reason I like that beast. Must be the oil/fuel perfume ... S.
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 9/14/2011 Posts: 989 Location: Buffalo, NY
|
Awesome project, can't wait to see the end result! Daily Diesel Dose.com| All Ready Mix.com | Plowsite DOT Thread | If your only contribution is complaining, please don't contribute!
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Works from last weekend: Ballast box and cab, then some of the decals. Box still needs more clear coat once completed. Must redo one of the side bars that have inaccurate angles, then add the lifting rings on the sides (in upwards position so the box and sidebars can be lifted; holes in box bottom are for metal screws which will allow for removal and replace by fithwheel if desired. Fenders will still remain in place): "/> "/> "/> "/> Fortunately even with the cab modification, the seam is barely noticeable: "/> "/> Next step is , then trim the cab interior so it fits in the smaller one, then customize the front bumper as shown here, thanks to Joe's valuable pictures: "/>
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 11/13/2012 Posts: 1,001 Location: South oz THE ASS END OF THE RIVER , Australia
|
looking good Stephane PM sent hope you doing step by step pics ;) those dakar wheels were ? i'm after 16 of them. .
Sent from my HTC M10 - Rooted , using S-OFF , Open Home 6 & Buuf icon packs http://forum.xda-developers.com/ BUILD YOUR OWN PHONE
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
I usually don't like to do a step-by-step post as I usually lead two or three projects altogether and it sometimes takes me forever to have one completed, also due to job concerns or other priorities. Both this one and the Weldex truck were started... in March. But since some have an interest knowing the making, I will do that once it's 80% near completion as in this case. Wheels: modified ASAM models. check your e-mails. Stephane
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 5/3/2007 Posts: 351 Location: France
|
Excellent work Stephane, realy it's a great idea to use the military Titan for make this model !!! Pat
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Well it's what is most similar as far as shared components. If only it would have been available via WSI Parts that would have made for a cheaper project, though. But I was determined to do it; it was just a matter of time and to figure out that I have sufficient skills to go ahead with it. But it cannot compare with your current project. I still do not machine brass parts in details as you do... S.
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 10/31/2006 Posts: 478 Location: Alexandria, Virginia
|
...What a fantastic job......like those tires !....Where's da Beef......
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Chip Carlin wrote:...What a fantastic job......like those tires !....Where's da Beef...... I've been wondering myself if it is still in service out there in Quatar. Sounds like it's been built back in 2006, acording to Joe's previous link. Can anyone from Mammoet who has access to their intranet or something let us know? May I push my luck even more and ask for supplemental pictures or videos than those found on Google when typing "Mammoet-titan-quatar-actros". Or maybe they're using different words in Nederlandese or German, I don't know. Thanks, S.
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 11/8/2005 Posts: 199 Location: Kinross, Scotland
|
Ironstef70 wrote:Oh yeah, excellent. Thanks! Stephane Anytime Steph,glad to help, Regards Joe.
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Been busy last weekend. The ballast box is completely finished, including all decals, service crane and the lifting rings. It fits perfectly on the truck's frame and I won't add screws as I intended to initially (hence why the holes in the box bed). "/> "/> "/> Next steps to completion: - Touch paint and finition on the front bumper, alignment of front lights with it, then glue on front end; - Cab roof details and fuel unit rebuilt. I ended up splitting the tank in two (had to break down the unit completely) and repainting following Joe's original pictures with details of the rear; - Customize side mirrors with wider supports and front grille. Most likely by next weekend I hope.
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 1/11/2007 Posts: 9,004 Location: Lincolnshire
|
Coming together very nicely!
Paul R
|
|
Rank: Advanced Member Groups: Member
Joined: 6/27/2013 Posts: 937 Location: Quebec, Canada,
|
Finally completed. I added more details such as custom brass pipe, mirrors, changed the front bumber lower bar, made the right side fuel tank, made the front grille, then put a hook and wire on service crane, maybe even more that I don't even remember of... Sorry for the pictures quality and reflections in the truck's paint: I used the cell phone but should have charged the camera battery... With all the steel parts added to it, it weights almostr three times the weight of the initial WSI truck. I should weight it one day Here are more pics of the 1:1 truck along with it: "/> "/> "/> "/> "/> "/> "/> "/> "/> "/> I'm doing a local expo this weekend at my local railroading club. Guys asked me to prepare a special booth with some of my die-cast collection. Will send picures in another post. Stephane
___________________________________________________ Playing with toys since 1970, now building them.
|
|
Rank: Advanced Member Groups: Member
Joined: 6/16/2014 Posts: 239 Location: Waterford, MI
|
That really turned out nice. Great job!
Lee
customstyrene@gmail.com
https://www.facebook.com/customsytrene
|
|
Rank: Advanced Member Groups: Member
Joined: 2/26/2008 Posts: 1,765 Location: Virginia
|
very nice!
|
|
